Forklift Drive Axle

Drive Axle Forklift - The piece of machinery which is elastically affixed to the framework of the vehicle with a lift mast is referred to as the forklift drive axle. The lift mast attaches to the drive axle and could be inclined, by at least one tilting cylinder, around the drive axle's axial centerline. Forward bearing components together with rear bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle can be pivoted around a swiveling axis oriented transversely and horizontally in the vicinity of the back bearing components. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is attached to the lift truck framework and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the swiveling axis to the axial centerline.

Lift truck units like H45, H35 and H40 that are manufactured in Aschaffenburg, Germany by Linde AG, have the lift mast tilt capably affixed\connected on the vehicle frame. The drive axle is elastically attached to the forklift framework utilizing a multitude of bearing devices. The drive axle has tubular axle body along with extension arms affixed to it and extend rearwards. This type of drive axle is elastically attached to the vehicle framework using back bearing elements on the extension arms along with forward bearing tools located on the axle body. There are two back and two front bearing tools. Each one is separated in the transverse direction of the lift truck from the other bearing machine in its respective pair.

The braking and drive torques of the drive axle on tis particular unit of forklift are sustained utilizing the extension arms through the back bearing components on the framework. The forces created by the load being carried and the lift mast are transmitted into the floor or roadway by the vehicle framework through the front bearing components of the drive axle. It is essential to be certain the elements of the drive axle are constructed in a rigid enough way in order to maintain immovability of the lift truck truck. The bearing elements can reduce slight bumps or road surface irregularities all through travel to a limited extent and offer a bit smoother function.
